QF-GJ-H-MD-1400-10-4/5
1.4M Joint stamping robot
- Built-in cable for easy deployment.
- Top brands key motion parts to achieve high speed, high stability and high reliability.
Service Hotline：
400-166-2658
Email：sales@qinfeng-gp.com
Website：robot.qinfeng-gp.com
| Model | QF-GJ-H-MD-1400-10-4/5 | ||
| Parameter | Unit | Index | |
| Maximum working radius | mm | 1400 | |
| Minimum working radius | mm | 350 | |
| Grip size | mm | ≤800╳800 | |
| Centre grip weight | kg | ≤10 | |
| Maximum SPM | pcs/min | 15 | |
| Positioning precision | mm | ±0.1 | |
| Body size (H is variable) (L*W*H) | mm | 1370╳600╳1980 | |
| Body weight | kg | ≈275 | |
Motion range (Maximum speed) | J1 | ° (°/s) | ±160 (143.9) |
J2 | ° (°/s) | -25, +75 (141.3) | |
J3 | ° (°/s) | -75, +75 (248.9) | |
J4 | ° (°/s) | ±300 (438.7) | |
J5 (N/A for 4 axes model) | ° (°/s) | ±180 (877.5) | |
